E-HOOK Mushroom Head Interlocking Fastener EH-4336
JIEHUAN E-HOOK EH-4336 mushroom head interlocking fastener features ABS injection-molded construction with self-adhesive backing. Screw-free, no-damage wall fixing with reusable reclosable bonding. Available in 5 sizes (S/M/L/XL/XXL). 1,000+ open/close cycle life.
Product Overview
The E-HOOK EH-4336 is a mushroom head interlocking fastener system engineered by JIEHUAN. Featuring ABS injection-molded mushroom heads that interlock with an audible click, this self-adhesive reclosable fastening solution enables screw-free, no-damage mounting on tiles, glass, wood, and painted walls.
Key Features
- Audible Click Lock: Clear click feedback confirms secure engagement every time
- Screw-Free Installation: No drilling, no wall damage; self-adhesive backing bonds to tiles, glass, wood, and painted surfaces
- Reusable and Reclosable: Open and close repeatedly without strength degradation; 1,000+ cycle life
- High Shear Strength: Static shear strength up to 17.22 N/cm2 (E2519 model)
- Hidden Fastening: Smooth, flush surface after engagement; clean aesthetic finish
- 5 Sizes Available: Small, Medium, Large, XL, XXL to match any load requirement
Technical Specifications
Model: E5619 | Material: ABS | Weight: 722 g/m2 | Thickness Uncoupled: 2.346 mm | Thickness Coupled: 3.142 mm | Shear Strength: 6.16 N/cm2 | T-Peel: 0.73 N/cm
Model: E2519 | Material: ABS | Weight: 792 g/m2 | Thickness Uncoupled: 2.381 mm | Thickness Coupled: 3.353 mm | Shear Strength: 17.22 N/cm2 | T-Peel: 0.73 N/cm
Model: E4326 | Material: PP | Weight: 347 g/m2 | Thickness Uncoupled: 1.735 mm | Thickness Coupled: 2.053 mm | Shear Strength: 9.62 N/cm2 | T-Peel: 0.51 N/cm
Application Surfaces
Suitable for indoor use on tiles, glass, wooden surfaces, painted walls (latex paint), and decorative panels. Designed for dry, low-to-medium temperature environments.
Shelf Life
24 months from date of manufacture.
Why Choose JIEHUAN?
- National High-Tech Enterprise (ISO 9001 certified)
- 25 years of hook and loop manufacturing expertise
- 32 patents, SGS tested, RoHS/REACH compliant
- Trusted by HUAWEI, BOE, DJO, SKG and 1,000+ clients worldwide
